1992-1996 Sea-Doo GTS 580 Specs and Review [Video]
The Sea-Doo GTS 580 was actually a relabeled 1991 Sea-Doo GT upgraded with hull strakes and a “White” Rotax 587 engine. This model remained in production until 1997 when the more advanced Sea-Doo GTS 720 replaced it.
If you want to learn all about this popular vintage machine, this post is for you.
We at JetDrift have compiled all you need to know into this 1992-1996 Sea-Doo GTS 580 review!
1992-1996 Sea-Doo GTS Review
Sea-Doo introduced its first three-seater runabout, the GT, for the 1990 model year.
This ski was built on a flat-bottom hull powered by a dual-carb “Yellow” Rotax 587 engine. The GT was then carried over for the 1991 season without any significant changes.
By 1992, Sea-Doo had rebranded its three-seater ski from GT to GTS. This model remained the entry-level three-seater runabout in the Sea-Doo fleet until 2000.
The revamped GTS 580 hull already featured strakes on its bottom for better handling and stability. They also did a really good job in tight turns!
Also, the paint job and decals went from blue to purple.
Aside from these changes, the rest of the machine was carried over from the GT.
Standard features of the 1992 Sea-Doo GTS 580 were as follows:
- Electric start (std.)
- Tether cord (std.)
- 8.7-gallon fuel tank (std.)
- 95 oz. oil reservoir (std.)
- Fuel tank reserve (std.)
- Overheating warning device (std.)
- Reverse (std.)
- Storage compartment (std.)
- Rear grab handle (std.)
- Electric fuel level gauge (opt.)
- Injection oil low-level warning device (opt.)
Regarding dimensions, the Sea-Doo GTS was 119.3 inches long, 47.6 inches wide, and 37.4 inches high, and weighed 461 pounds.
Like its predecessor, the 1992 Sea-Doo GTS 580 was powered by a single-carb Rotax 587 engine. However, this power source was already the more advanced “White” engine version.
This 580cc, 2-stroke twin produced 56 HP at 5750 RPM and 64 Nm (47 lb.-ft.) torque at 5500 RPM.
Unlike the sporty XP 580 and the higher-level twin-carb GTX, the GTS only featured a single Mikuni carburetor.
For the 1993 season, the dimensions of the GTS platform had been slightly decreased. The new model measured 119 inches in length, 46.9 inches in width, and 37.4 inches in height. However, its dry weight increased from 461 to 465 pounds.
This GTS platform remained basically unchanged until the 2000 season. For the 1995 model year, the ski got a larger, 12-gallon fuel tank and a 1.2-gallon oil reservoir.
The Sea-Doo GTS saw a major upgrade in 1997 when its Rotax 587 engine was replaced with the more powerful single-carb Rotax 717.
The latter was a 718cc 2-stroke twin featuring a single Mikuni BN-40I carburetor, CDI ignition, open-loop cooling, and an oil injection system. Thanks to these features, the single-carb Rotax 717 cranked out 85 HP.
Referring to the engine option, this model was also known as the “Sea-Doo GTS 720.”
This setup remained in production until 2001 when it was replaced by the all-new 2001 Sea-Doo GTS.
Despite the debute of the new model, the “old” GTS 720 was still marketed in the 2001 model year.
1992 Sea-Doo GTS 580 Specs Chart
For your convenience, we’ve compiled the 1992 Sea-Doo GTS 580 specifications into these charts!
Dimensions
1992 Sea-Doo GTS | Dimensions and Capacities |
---|---|
Number of passengers | 1 operator and 2 passengers |
Overall length | 303 cm (119.3 in) |
Overall width | 121 cm (47.6 in) |
Overall height | 95 cm (37.4 in) |
Weight | 209 kg (461 lb) |
Load limit | 225 kg (496 lb) |
Hull Material | Composite (fiberglass) |
Fuel tank | 33 L (8.7 US gal) |
Impeller shaft reservoir - Capacity | 65 mL (2.2 US oz) |
Impeller shaft reservoir - Oil level height | up to plug |
Injection oil reservoir | 2.8 L (95 US fl oz) |
Engine Specs
1992 Sea-Doo GTS | Engine Specs |
---|---|
Engine type | Rotax 2-stroke, type 587 |
Induction type | Rotary valve |
Exhaust system | Water cooled/water injected |
Exhaust valve | |
Lubrication - type | Oil injection |
Lubrication - oil type | Sea-Doo Injection Oil |
Number of cylinders | 2 |
Bore | 76.0 mm (2.992 in) |
Stroke | 64.0 mm (2.520 in) |
Displacement | 580.7 cm3 (35.43 in3) |
Compression Ratio (corrected) | 5.9 : 1 |
Maximum Power (approximately) | 56 HP |
Maximum Torque (approximately) | 64 Nm (47 lbf.ft) at 5500 RPM |
RPM Limiter Operation @ | 6550 RPM ± 100 |
Cooling Type | Water cooled, total loss type - Direct flow from propulsion unit |
Overheating Beeper, Switch On @ | 96-99 °C (205-210°F) |
Carburation
1992 Sea-Doo GTS | Carburation |
---|---|
Fuel - type | Regular unleaded gasoline |
Carburetor - type and number | Diaphragm type - Quantity : 1 |
Carburetor adjustments - Low-speed mixture screw | 1 Turn ± 1/4 turn |
Carburetor adjustments - Idle speed | 1400 RPM |
Propulsion
1992 Sea-Doo GTS | Propulsion |
---|---|
Propulsion system | Bombardier Formula pump |
Jet pump type | Axial flow, single stage |
Impeller Rotation (seen from rear) | Counter-clockwise |
Transmission | Direct drive |
Coupling Type | Crown Splines |
Impeller shaft reservoir oil type | Sea-Doo synthetic oil polyolester 75W90 Gear Lube - P/N 293 600 011 |
Pivoting angle of direction (nozzle) | ~ 26° |
Pivoting angle of variable trim system | NA |
Minimum required water level for jet pump | 90 cm (3 ft) |
Impeller Diameter | 139.5 mm (5.49 in) |
Electrical Features
1992 Sea-Doo GTS | Electrical Features |
---|---|
Magneto generator output | 160 W @ 6000 RPM |
Ignition system type | Capacitor Discharge Ignition (Breakerless) |
Spark plug - Make and type | NGK BR7ES |
Spark plug - Gap | 0.5 - 0.6 mm (0.020-0.024 in) |
Starting system | Electric starter |
Ignition timing - BTDC | 2.65 mm (0.104 in) (21 ° ± 1°) |
Ignition timing - Note | Checked with engine cold. Marks must align @ 6000 RPM) |
Battery | 12 V, 19 A |
Starting system Fuse | 5 A |
Charging system Fuse | 15 A |
Gauges Fuse | NA |
Performance
1992 Sea-Doo GTS | Performacne |
---|---|
Horsepower | 56 HP |
Cruising time at full throttle - Fuel tank without reserve | ~ 1.45 hours |
Cruising time at full throttle - Fuel tank reserve | ~ 20 minutes |
Maximum Speed * | NA |
* Top speed may vary depending on operator and passenger weight, water conditions, wind, current, altitude etc. |
These charts are for informational purposes only! For exact specifications, please refer to the factory manual.
Vintage Sea-Doo GTS 580 For Sale
If you are considering purchasing one, you probably want to know where to find a Sea-Doo GTS 580 for sale. As this model vanished from the market in 1996, it’s already a collectible item, so finding one is not an easy task!
We recommend that you start your research on dedicated Sea-Doo forums and Facebook fan groups. Aside from some good deals, you may find some valuable info there about this ski.
Besides these sources, you may also find some used Sea-Doo GTS 580s for sale on Craigslist, PWC Trader, and other dedicated jet ski swap sites.
Takeaway
As a takeaway, we’ve answered the most common questions about the Sea-Doo GTS 580!
What is a Sea-Doo GTS 580?
The Sea-Doo GTS 580 was a vintage 3-seater sit-down jet ski manufactured by BRP.
What Year did Sea-Doo Make the GTS 580?
Sea-Doo marketed the GTS 580 from 1992 through 1996.
Was the Sea-Doo GTS 580 a 2-Stroke Ski?
Yes, the Sea-Doo GTS 580 utilized a 2-stroke twin engine.
How Many People Could Ride a Sea-Doo GTS 580?
The tiny Sea-Doo GTS 580 was rated for three riders, but riding with two adult passengers was virtually impossible!
What Size was the Sea-Doo GTS 580?
The 1992 Doo GTS 580 was 119.3 inches long, 47.6 inches wide, and 37.4 inches high, while the 1993-1996 models measured 119 inches in length, 46.9 inches in width, and 37.4 inches in height.
How Much Did a Sea-Doo GTS 580 Weigh?
The dry weight of the 1992 Sea-Doo GTS 580 was only 465 pounds.
What Kind of Engine Did the Sea-Doo GTS 580 Have?
The 1992-1996 Sea-Doo GTS 580 was powered by the single-carb “White” Rotax 587 engine.
How Much Horsepower Did a 1992-2000 Sea-Doo GTS Have?
The 1992-1996 Sea-Doo GTS 580 provided 56 HP.
Did the Sea-Doo GTS 580 Have Reverse?
Yes, the Sea-Doo GTS was equipped with manual reverse.
What Size Storage Compartment Did a Sea-Doo GTS 580 Have?
The Sea-Doo GTS 580 featured a 13.2-gallon front storage.
How Much Weight Could a Sea-Doo GTS 580 Hold?
The total weight capacity of the Sea-Doo GTS 580 was 496 pounds.
How Much Fuel Did a Sea-Doo GTS 580 Hold?
The 1992-1994 Sea-Doo GTS utilized an 8.7-gallon fuel tank, while the 1995-1996 models got a larger, 12-gallon fuel cell.
How Much Fuel Did a 1992-1996 Sea-Doo GTS 580 Use?
The fuel consumption of the 1992-1996 Sea-Doo GTS 580 was about 5.3 GPH.
Could the Sea-Doo GTS 580 Tow a Skier or a Wakeboarder?
Yes, the Sea-Doo GTS 580 was rated for three riders, so it could legally tow a skier. However, its tippy hull was not the best option for tow sports.
How Fast Did a 1992-1996 Sea-Doo GTS 580 Go?
The top speed of a single-carb 1992-1996 Sea-Doo GTS 580 was about 36 mph under ideal conditions.
How Much is a 1992-1996 Sea-Doo GTS 580 Worth?
It’s hard to tell the exact price of a Sea-Doo GT, as it strongly depends on its year, condition, and location. But as a rule of thumb, the prices typically range from $500 up to $2,000.
