2022 Yamaha EX Limited Review and Specs [Video]

Home/News/2022 Yamaha EX Limited Review and Specs [Video]

The 2022 Yamaha EX Limited is considered to be the flagship model in the Yamaha EX family. This high-end model shares its TR-1 Yamaha Marine Engine and nimble EX platform with the rest of the EX line as well as the sporty JetBlaster. Also, the EX Limited comes with a wide range of accessories like advanced sponsons, Yamaha RiDe system, and a tow package.

 If you want to find out more about the EX Limited, you’ve come to the right place.

We at JetDrift have compiled all you need to know into this Yamaha EX Limited review!

2022 Yamaha EX Limited Review

The Yamaha EX family was revealed in 2017 to compete with the unique Sea-Doo Spark series in the Rec-Lite PWC category. The youngest member of this line is the Yamaha EX Limited, which made its debut in 2021.

With this new model, the 2022 Yamaha EX WaveRunner series consists of four different skis including:

(You can discover these models by following the links above.)

Each of these skis shares the same hull and engine, but the EX Limited stands out in the crowd, as this model comes with many useful features and accessories.

The key feature of the EX Limited is arguably its RiDE brake and reverse system, which can be controlled directly from the handlebars. What’s more, the system also makes the ski easy to maneuver around docks and in tight places.

Besides the RiDE, the EX Limited is also equipped with dual mirrors, a reboarding step, pull-up-cleats, branded fenders, matching cover, portable jet ski speakers, and a larger waterproof front storage bag.

Also, the EX Limited comes with a standard “tow package” including a tube, a 12V tube inflator, and a tow rope. Another innovative feature on this ski is its advanced sponsons, which make the hull more stable if you ride with a passenger.

Except for this equipment and the colors, the Yamaha EX Limited is identical to the basic Yamaha EX. If you are not familiar with the this base model, we highly recommend that you start with this review here!

2022 Yamaha EX Limited Specs Chart

For your convenience, we’ve listed the Yamaha EX Limited specifications in these charts!

2022 Yamaha EX Limited Engine Specs

Engine Specs
Engine typeLiquid cooled 4-stroke (DOHC)
Number of cylinders3
Bore x Stroke82.0 x 66.2 mm (3.23 x 2.61 in)
Displacement1 049 cm³
Compression ratio11.0 :1
Cooling SystemWater
Lubrication SystemDry sump
Starting SystemElectric
Ignition SystemT.C.I.
Spark plugNGK -CR9EB
Spark plug Gap0.7 - 0.8 mm (0.028 to 0.031 in)
Battery typeYTX20L-BS
Battery capacity12 V, 18 Ah
Charging SystemFlywheel magneto

2022 Yamaha EX Limited Fuel and Oil Specs

Fuel and Oil Specs
Recommended fuelRegular unleaded gasoline
Fuel Recommended OctaneMinimum octane rating (PON): 86 - Minimum octane rating (RON): 90
Recommended engine oilYamalube 4W or 4-stroke motor oil
Fuel tank total capacity50 L (13.2 US gal)
Engine oil total quantity 3.7 L (3.91 US qt)

2022 Yamaha EX Limited Performance

Performance
Maximum Output74.6 kW at 7300 r/min
Maximum Fuel Consumption7.7 US gal/h (29.2 L/h)
Cruising Range / at full throttle1.71 hours
Trolling speed1500 +/-100 r/min

2022 Yamaha EX Limited Propulsion

Drive Unit
Propulsion systemJet pump
Jet pump typeAxial flow, single stage
Impeller rotationCounter clockwise
Jet thrust nozzle angle24 + 24°

2022 Yamaha EX Limited Dimensions and Capacities

Dimensions and Capacities
Overall length3.13 m (123.2 in)
Overall width1.13 m (44.5 in)
Overall height1.15 m (45.3 in)
Dry weight578 lb (262 kg)
Number of passenger (driver incl.)3
Maximum load capacity496 lb (225 kg)

These charts are for informational purposes only! For exact specifications, please refer to the factory manual.

Yamaha EX Comparison Chart

We’ve also compiled the key differences between the EX WaveRuner models into one chart:

Yamaha EX vs. EX Sport vs. EX Deluxe vs. EX Limited Comparison

FeaturesBase EXEX SportEX DeluxeEX Limited
ReverseNoYes (Mechanical)Yes (RiDE)Yes (RiDE)
BrakeNoNoYes (RiDE)Yes (RiDE)
MirrorsNoYesYesYes
Reboarding StepNoYesYesYes
Pull-up cleatsNoNoNoYes
Portable speakersNoNoNoYes
Tow packageNoNoNoYes
Large watertight bow storageNoNoNoYes
Branded fendersNoNoNoYes
Branded coverNoNoNoYes
SponsonsNormalNormalNormalAdvanced

Takeaway

As a takeaway, we’ve answered the most common questions about the Yamaha EX Limited!

What is a Yamaha EX Limited?

The Yamaha EX Limited is one of the cheapest Yamaha WaveRunner available. This model was introduced in 2017 and classed in the Rec-Lite category.

What is the Difference Between the Yamaha EX and EX Limited?

It’s safe to say that the Yamaha EX Limited is a base Yamaha EX equipped with the RiDE system, reboarding step, dual mirrors, pull-up cleats, and a set of accessories like the tow package, portable speakers, fenders, and a matching cover.

What Size is a Yamaha EX Limited?

The Yamaha EX Limited is 123.6 inches long, 44.5 inches wide, and 45.3 inches high.

How Much Does a Yamaha EX Limited Weigh?

The dry weight of the Yamaha EX Limited is a remarkable 602 pounds, but you can expect the curb weight of this machine to be about 690 pounds.

What Kind of Engine is in the Yamaha EX Limited?

The engine of the Yamaha EX Limited is the reliable TR-1 Yamaha Marine Engine. This 1049cc, 4-stroke triple features an electronic fuel injection system and open-loop water cooling.

How Much Horsepower Does a Yamaha EX Limited Have?

The lively Yamaha EX Limited is officially rated at 100 HP.

Is the Yamaha EX Limited Supercharged?

No, the Yamaha EX Limited is not supercharged, as it’s powered by the naturally-aspirated TR-1 engine.

How Fast Can a Yamaha EX Limited Go?

The top speed of the Yamaha EX Limited is about 50-51 mph in stock condition, which can be increased to the 55-58 mph range with some aftermarket performance modifications.

How Fast Does a Yamaha EX Limited Go From 0 to 60?

The Yamaha EX Limited can go from 0 to 30 mph in 2.3 seconds.

How Much Weight Can a Yamaha EX Limited Hold?

The total weight capacity of the Yamaha EX Limited is 496 pounds.

How Much Fuel Does a Yamaha EX Limited Hold?

The Yamaha EX Limited is equipped with a 13.2-gallon fuel tank.

How Much Fuel Does a Yamaha EX Limited Use?

The Yamaha EX Limited burns 3.2 gallons per hour (GPH) at a speed of 29 mph and 7.9 GPH at 51 mph.

What is the Range on a Yamaha EX Limited?

Depending on the external conditions, the load, and your riding style, the fuel range of this ski varies widely. But as a rule of thumb, the fuel range of the Yamaha EX Limited is about 100-120 miles at best cruise speed and 80-85 mph at full speed.

Again, pretty average numbers, as the fuel range of a jet ski depends on many factors!

Does the 2022 Yamaha EX Limited Have Reverse?

Yes, the 2022 Yamaha EX Limited comes with brake and reverse system.

Does the 2021 Yamaha EX Limited Have RiDE?

Yes, Yamaha EX Limited features the innovative Yamaha RiDE system.

Does 2022 Yamaha EX Limited Have Trim?

No, the 2022 Yamaha EX Limited is manufactured without a trim system.

What are the Color Options of the 2022 Yamaha EX Limited?

The 2022 Yamaha EX Limited is available in a “Azure Blue with Mint” color scheme.

Is the Yamaha EX Limited Stable?

It’s safe to say that the Yamaha EX Limited is a stable ski with one or two smaller adult riders. With two bigger or even three riders onboard its tiny hull becomes unstable and tipsy. This is why this ski is primarily recommended for solo rides!

Do Yamaha EX Limited Have Speakers?

Detachable, floating speakers are available for the Yamaha EX Limited series as an option.

Can You Tow With a Yamaha EX Limited?

Although it is possible to tow with a Yamaha EX Limited, it’s not the best jet ski for tow sports.

How Many Passengers Can the Yamaha EX Limited Carry?

Although the Yamaha EX Limited can carry 3 adult passengers legally, this ski is offered for solo rides or a maximum of two average adult people.

What Size Storage Compartment Does the Yamaha EX Limited Have?

The Yamaha EX Limited features a convenient glovebox, wet front storage, and under-seat storage with a total capacity of 7.7 gallons.

How Long is the Factory Warranty on a Yamaha EX Limited?

The factory warranty covers the Yamaha EX Limited for one year.

How Much Does a Yamaha EX Limited Cost?

In 2022, the Yamaha EX Limited is available for an MSRP of $9,899.

Where Can You find a Yamaha EX Limited For Sale?

If you are in the market for a Yamaha EX Limited, don’t hesitate to contact the manufacturer’s official site.
