1994 Sea-Doo GTX 650 Specs and Review [Video]
The 1994 Sea-Doo GTX 650 was a more powerful successor of the 1993 GTX 580. This revamped model came with many advanced features, including the dual-carb Rotax 657 engine, bronze vane jet pump, mirrors, and a set of gauges.
If you want to learn all about this vintage 2-stroke Sea-Doo, you’ve come to the right place.
We at JetDrift have compiled all you need to know into this 1994 Sea-Doo GTX 650 review!
1994 Sea-Doo GTX 650 Review
The 1994 Sea-Doo GTX 650 (a.k.a. Sea-Doo GTX 657) replaced the underpowered GTX 580.
Although the new GTX 650 inherited its platform from its predecessor, it came with a more powerful, dual-carb Rotax 657 engine rated at 70 HP. This power mill was a 650cc, 2-stroke twin featuring a CDI ignition, open-loop cooling system, oil injection, and two diaphragm-type Mikuni carburetors.
As expected, the larger displacement resulted in worse fuel consumption figures. The GTX 650 had about 7.8 GPH at WOT, so its 8.7-gallon fuel tank offered a cruising time of just 1 hour and 10 minutes.
Besides the engine, the propulsion system of the GTX also saw a major upgrade, as it came with the more durable Bombardier bronze vane pump.
Regarding dimensions, the GTX 650 was 119 inches long, 46.9 inches wide, and 47.4 inches high, and it weighed 484 pounds. The ski was built on the “straked” GTS/GTX hull, pretty much the same as you would find under 1992-1993 3-seater Sea-Doo models.
Color scheme?
The body of the ski had a green/white color scheme with a purple handlebar cover, rear grab handle, and rub rails.
Keeping tow sports in mind, the 1994 GTX 650 was also equipped with mirrors and a gauge set, including a digital fuel gauge with an injection oil pilot lamp and an analog speedometer.
Thanks to these advanced features and the more powerful engine, the GTX 650 was popular among wakeboarders and water skiers.
Other standard features on the GTX 650 included:
- Electric start
- Handlebar-mounted engine stop button
- Tether cord
- 8.7-gallon fuel tank
- 95 oz. oil reservoir
- Fuel tank reserve
- Deck mats
- Overheating warning device
- Manual reverse
- Removable storage compartment
- Rear grab handle
- Rear vent grill
- Docking eyelets
- Speedometer
- Bile drain plugs
- Fuel level gauge (with low-oil warning light)
- Electric fuel level gauge
- Injection oil low-level warning device
- Water tank trap drains
- Dual mirrors
- Tool kit
Even though the GTX was marketed as a 3-seater runabout, it became very tippy with three adult riders onboard. Therefore, this ski was actually only comfortable for two adults.
By 1995, Sea-Doo replaced the GTX engine with the more advanced Rotax 657x.
Over the years, the 2-stroke Sea-Doo GTX family underwent many upgrades and generations, including:
- 1993 Sea-Doo GTX 580 (Rotax 587)
- 1994 Sea-Doo GTX 650 (Rotax 657)
- 1995 Sea-Doo GTX 650 (Rotax 657x)
- 1996-1997 Sea-Doo GTX 800 (Rotax 787)
- 1998-1999 Sea-Doo GTX Limited (Rotax 947)
- 2000-2002 Sea-Doo GTX 951 Millennium (Rotax 947)
- 1998-2001 Sea-Doo GTX RFI (Rotax 787 RFI)
- 2000-2001 Sea-Doo GTX DI (Rotax 947 DI)
- 2002-2003 Sea-Doo GTX DI (Rotax 947 DI)
1994 Sea-Doo GTX 650 Specs Chart
For your convenience, we’ve compiled the 1994 Sea-Doo GTX 650 specifications into these charts!
1994 Sea-Doo GTX 650 Dimensions
| 1994 Sea-Doo GTX 650 | Dimensions and Capacities |
|---|---|
| Number of passengers | 1 operator and 2 passengers |
| Overall length | 303 cm (119 in) |
| Overall width | 121 cm (46.9 in) |
| Overall height | 95 cm (37.4 in) |
| Weight | 209 kg (484 lb) |
| Load limit | 225 kg (496 lb) |
| Hull Material | Composite (fiberglass) |
| Fuel tank | 33 L (8.7 US gal) |
| Impeller shaft reservoir - Capacity | 65 mL (2.2 US oz) |
| Impeller shaft reservoir - Oil level height | up to plug |
| Injection oil reservoir | 2.8 L (95 US fl oz) |
1994 Sea-Doo GTG 650 Engine Specs
| 1994 Sea-Doo GTX 650 | Engine Specs |
|---|---|
| Engine type | Rotax 657, 2-stroke |
| Induction type | Rotary valve |
| Exhaust system | Water cooled/water injected |
| Lubrication - type | Oil injection |
| Lubrication - oil type | Sea-Doo Injection Oil |
| Number of cylinders | 2 |
| Displacement | 650 cm3 (39.66 in3) |
| Maximum Power (approximately) | 70 HP |
| RPM Limiter Operation @ | 7000 RPM ± 100 |
| Cooling Type | Water cooled, total loss type - Direct flow from propulsion unit |
| Fuel - type | Regular unleaded gasoline |
| Carburetor - type and number | Diaphragm type - Quantity: 2 |
1994 Sea-Doo GTX 650 Propulsion
| 1994 Sea-Doo GTX 650 | Propulsion |
|---|---|
| Propulsion system | Bombardier Formula pump |
| Jet pump type | Axial flow, single-stage |
| Transmission | Direct drive |
| Impeller shaft reservoir oil type | Sea-Doo synthetic oil polyolester 75W90 Gear Lube – GL5 |
| Pivoting angle of direction (nozzle) | ~ 26° |
| Minimum required water level for jet pump | 90 cm (3 ft) |
1994 Sea-Doo GTX 650 Electrical Features
| 1994 Sea-Doo GTX 650 | Electrical Features |
|---|---|
| Magneto generator output | 160 W @ 6000 RPM |
| Ignition system type | Capacitor Discharge Ignition (Breakerless) |
| Spark plug - Make and type | NGK BR8ES |
| Spark plug - Gap | 0.5 - 0.6 mm (0.020-0.024 in) |
| Starting system | Electric starter |
| Battery | 12 V, 19 A |
| Starting system Fuse | 5 A |
| Charging system Fuse | 15 A |
1994 Sea-Doo GTX 650 Performance
| 1994 Sea-Doo GTX 650 | Performance |
|---|---|
| Horsepower | 70 HP |
| Cruising time at full throttle - Fuel tank without reserve | ~ 1.10 hours |
| Cruising time at full throttle - Fuel tank reserve | ~ 10 minutes |
| Maximum Speed * | NA |
| * Top Speed may vary depending on operator and passenger weight, water conditions, wind, current, altitude etc. |
These charts are for informational purposes only! For exact specifications, please refer to the factory manual.
Sea-Doo GTX Comparison Chart
| Year | Model | Engine | HP | Weight (lbs) |
|---|---|---|---|---|
| 93 | GTX 580 | Rotax 587 | 60 | 465 |
| 94 | GTX 650 | Rotax 657 | 70 | 484 |
| 95 | GTX 650 | Rotax 657x | 80 | 484 |
| 96-97 | GTX 800 | Rotax 787 | 110 | 578 |
| 98-99 | GTX LTD | Carbed Rotax 947 | 130 | 645 |
| 98-01 | GTX RFI | Rotax 787 RFI | 110 | 642 |
| 00-02 | GTX 951 | Carbed Rotax 947 | 130 | 662 |
| 00-01 | GTX DI | Rotax 947 DI | 130 | 680 |
| 02-03 | GTX DI | Rotax 947 DI | 130 | 715 |
1994 Sea-Doo GTX 650 For Sale
If you are considering purchasing one, you probably want to know where to find a Sea-Doo GTX 650 for sale. As this model vanished from the market in 1994, it’s already a collectible item, so finding one is not an easy task!
We recommend that you start your research on dedicated Sea-Doo forums and Facebook fan groups. Aside from some good deals, you may find some valuable info there about this ski.
Besides these sources, you may also find some used 1994 Sea-Doo GTX 650s for sale on Craigslist, PWC Trader, and other dedicated jet ski swap sites.
Takeaway
As a takeaway, we’ve answered the most common questions about the 1994 Sea-Doo GTX 650!
What is a Sea-Doo GTX 650?
The Sea-Doo GTX 650 was a vintage 3-seater sit-down PWC manufactured by BRP.
What Year did Sea-Doo Make the GTX 650?
Sea-Doo marketed the GTX 650 from 1994 through 1995.
How Many People Could Ride a 1994 Sea-Doo GTX 650?
The Sea-Doo GTX 650 was rated for three riders, but riding with two adult passengers was virtually impossible!
What Size was the 1994 Sea-Doo GTX 650?
The 1994 Sea-Doo GTX 650 was 119 inches long, 46.9 inches wide, and 37.4 inches high.
How Much Did a 1994 Sea-Doo GTX 650 Weigh?
The dry weight of the 1994 Sea-Doo GTX 650 was 484 pounds.
What Kind of Engine Did the 1994 Sea-Doo GTX 650 Have?
The 1994 Sea-Doo GTX 650 was powered by the dual-carb Rotax 657 engine.
How Much Horsepower Did a 1994 Sea-Doo GTX Have?
The 1994 Sea-Doo GTX 650 provided 70 HP.
Did the 1994 Sea-Doo GTX 650 Have Reverse?
Yes, the Sea-Doo GTX 650 was equipped with manual reverse.
What Size Storage Compartment Did a 1994 Sea-Doo GTX 650 Have?
The Sea-Doo GTX 650 featured a 13.2-gallon front storage.
How Much Weight Could a 1994 Sea-Doo GTX 650 Hold?
The total weight capacity of the Sea-Doo GTX 650 was 496 pounds.
How Much Fuel Did a 1994 Sea-Doo GTX 650 Hold?
The 1994 Sea-Doo GTX utilized an 8.7-gallon fuel tank.
How Much Fuel Did a 1994 Sea-Doo GTX 650 Use?
The fuel consumption of the 1994 Sea-Doo GTX 650 was about 7.8 GPH.
Could the Sea-Doo GTX 650 Tow a Skier or a Wakeboarder?
Yes, the Sea-Doo GTX 650 was rated for three riders, so it could legally tow a skier.
Was the Sea-Doo GTX 650 a 2-Stroke Ski?
Yes, the Sea-Doo GTX 650 utilized a 2-stroke twin engine.
How Fast Did a 1994 Sea-Doo GTX 650 Go?
The top speed of a 1994 Sea-Doo GTX 650 was about 42-43 mph under ideal conditions.
How Much is a 1994 Sea-Doo GTX 650 Worth?
It’s hard to tell the exact price of a 1994 Sea-Doo GTX 650, as it strongly depends on its year, condition, and location. But as a rule of thumb, the prices typically range from $500 up to $2,000.
