Yamaha FX Limited SVHO Review and Specs [Video]

Yamaha FX Limited SVHO Review and Specs [Video]

Yamaha released its flagship 2022 FX Limited SVHO to compete with the rivals Kawasaki Ultra 310 LX and Sea-Doo GTX Limited 300. Just like any other model in its high-end FX family, this model is built on the stable FX WaveRunner platform and comes with all the bells and whistles you would ever need on your trips!

If you want to find out more about this ski, this post is for you. We at JetDrift have compiled all you need to know into this Yamaha FX Limited SVHO review!

Yamaha FX Limited SVHO Review

Dimensions and Capacities

The FX Limited SVHO is considered the top-of-the-line WaveRunner in the Yamaha’s fleet, so it is no surprise that this ski is built on the largest WaveRunner platform.

This 140.9-inch long and 50-inch wide hull offers outstanding stability and capacities.

You can store plenty of gear in the large front storage, the smaller under-seat storage, and the watertight glovebox, which offer a total storage capacity of 44 gallons. With long tours in mind, the FX Limited SVHO utilizes an 18.5-gallon fuel tank.

On top of that, the machine can legally carry three adult riders comfortably, with a total weight capacity of 529 pounds.

Drawbacks?

Mainly its weight, as the dry weight of the 2022 Yamaha FX Limited SVHO is no less than 877 pounds. With the necessary liquids and fuel, you can expect the curb weight of this machine to be around 950-1000 pounds!

Unlike its predecessors manufactured exclusively from the lighter NanoXcel2, the hull of the latest FX WaveRunner is made of SMC fiberglass. This material is proven to be more durable and easier to repair, but on the other hand, it is heavier than NanoXcel2.

Let’s move on and take a look under the hood!

Yamaha FX Limited SVHO Engine and Propulsion

The engine of the Yamaha FX Limited SVHO is the proven 1.8-liter supercharged SVHO Yamaha Marine engine.

The key features of this power mill are as follows:

This 4-cylinder SVHO (Super Vortex High Output) engine offers the largest displacement in the industry, which results in high durability and reliability. In contrast, the flagship Sea-Doos are powered by a 1630cc, 3-cylinder supercharged Rotax engine, rated at 300 HP.

The direct driveshaft transmits power towards the 160mm high-pressure jet pump. This axial-flow pump features a 3-blade stainless steel impeller with a 17.6° pitch.

Just like any other WaveRunner engine, this unit is cooled with an industry-standard open-loop cooling system.

Yamaha FX Limited SVHO Performance and Handling

Thanks to its high-performance power source, the top speed of the 2022 Yamaha FX Limited SVHO is about 65-68 mph in stock condition.

In accordance with the cooperation between the U.S. Coast Guard and PWC manufacturers, the top speed of WaveRunners is electronically restricted. Overriding this speed limiter results in a 7-8 mph increase in speed, but the ski coud actually hit an amazing 80-85 mph with some additional aftermarket modifications.

These mods are only intended for closed-course competition, of course.

When it comes to the riding experience, it’s safe to say that this ski is much less playful than its smaller brothers. Its large hull is less nimble and not as lively due to its weight and dimensions.

If you compare this ski to the EX family or to its vintage predecessors, the difference is day and night.

Just look at the picture below; the difference in size between this WaveRunner and its vintage predecessor (WR500) is huge.

Yamaha FX Limited SVHO vs. Yamaha WaveRunner 500Let’s face it, the FX Limited SVHO is not designed for playing around. Instead, it’s a stable and comfortable WaveRunner that can be used for various purposes like tow sports, fishing, or even touring.

Thanks to its supercharged engine, it offers thrilling adrenalin rushes, but it won’t do any sit-down jet ski tricks like spins, power slides, or submarine.

Yamaha FX Limited SVHO Features and Accessories

The list of Yamaha FX Limited SVHO features is nearly endless, but the most important ones are as follows:

  • RiDE by Yamaha: Brake and Reverse system
  • Reverse Assist Mode
  • 7″ Connext Infotainment System with Color Touchscreen
  • Drive Control/Low RPM Mode
  • Cruise Assist/No Wake Mode
  • Electric Trim System
  • Steering Adjustment: Tilt
  • Molded in Cooler Storage in Bow
  • Dual Mirrors
  • Beverage Holder on Dash
  • Reboarding Step
  • Footwell Drains
  • Multi-Mount System
  • Two-Tone Deck Mats
  • Tow Hook
  • Watertight Under seat Storage
  • Fast Access Stern Storage
  • Extra Large Watertight Glovebox
  • Dual Rope Hook
  • Automatic Bilge Pump
  • 12V Battery
  • Bluetooth Capable
  • Audio Control
  • Make and Receive Phone Calls
  • GPS Map-Capable (with geo-fencing)
  • Pull up Cleats
Besides these features, the ski comes standard with a unique accessory package including:
  • Factory Installed Audio System (featuring two 4.5” waterproof Bluetooth speakers with a two-channel amplifier, low-voltage regulator and a control pad.)
  • Garmin® Striker™ GPS Fish Finder w/ Transducer
  • RAM® Multi-Mount Hardware
  • “Tow package” (tow rope, a sinlge tube with inflator and holder)
  • 12 volt Outlet
  • Custom Cover
  • Custom Designed Soft-Sided Yamaha Cooler
  • Two Fenders

Yamaha FX Limited SVHO Specs Chart

For your convenience, we’ve listed the 2022 Yamaha FX Limited SVHO specifications in these charts!

Yamaha FX Limited SVHO Dimensions and Capacities

Yamaha FX Limited SVHODimensions and Capacities
Overall length3.58 m (140.9 in)
Overall width1.27 m (50.0 in)
Overall height1.23 m (48.4 in)
Dry weight373 kg (822 lb)
Maximum load capacity240 kg (530 lb)
Number of passenger (driver incl.)3

Yamaha FX Limited SVHO Engine Specs

Yamaha FX Limied SVHOEngine Specs
Engine typeLiquid cooled 4-stroke (DOHC)
InductionSupercharged intercooled
Number of cylinders4
Bore x Stroke86.0 x 78.0 mm (3.39 x 3.07 in)
Displacement1 812 cm³
Compression ratio8.5:1
Cooling SystemWater
Lubrication SystemWet sump
Engine Recommended oilXPS Recommended Engine Oil - 4T 5W40 Synthetic blend oil
Engine Oil Capacity3 l (3.2 qt(liq.,US)) oil change w/ filter 5 l (5.3 qt(liq.,US)) total
Recommended fuelPremium unleaded gasoline
Fuel Recommended OctaneMinimum octane rating (PON): 91 - Minimum octane rating (RON): 95
Recommended engine oilYamalube 4W or 4-stroke motor oil
Fuel tank capacity70 L (18.5 US gal)
Engine oil total quantity5.3 L (5.60 US qt)

Yamaha FX Limited SVHO Performance

Yamaha FX Limied SVHOPerformance
Maximum Output184kW (247 HP)
Maximum Fuel Consumption21.3 US gal/h (80.7 L/h)
Cruising Range / at full throttle0.87 hours
Trolling speed1250 +/-100 r/min

Yamaha FX Limited SVHO Drive Unit

Yamaha FX Limied SVHODrive Unit
Propulsion systemJet pump
Jet pump typeAxial flow single stage
Impeller rotationCounter clockwise
Jet thrust nozzle angle24 + 24°
Jet thrust nozzle trim angle/- 5, -3, 0, 3, 6°

Yamaha FX Limited SVHO Electric Features

Yamaha FX Limied SVHOElectric Features
Starting SystemElectric
Ignition SystemT.C.I.
Spark plugNGK - LFR7A
Spark plug Gap0.8 to 0.9 mm (0.031 to 0.035 in)
Battery typeYTX20L-BS
Battery capacity12 V, 18 A•h
Charging SystemFlywheel magneto
These charts are for informational purposes only! For exact specifications, please refer to the factory manual.

Takeaway

As a takeaway, we’ve answered the most common questions about the Yamaha FX Limited SVHO!

What Size is a Yamaha FX Limited SVHO?

The Yamaha FX Limited SVHO is 140.9 inches long, 50 inches wide, and 48.4 inches high.

How Much Does a Yamaha FX Limited SVHO Weigh?

The dry weight of the Yamaha FX Limited SVHO is a remarkable 877 pounds, but you can expect the curb weight of this ski to be about 950-1,000 pounds.

What Kind of Engine is in the Yamaha FX Limited SVHO?

The engine of the Yamaha FX Limited SVHO is the proven 4-stroke 1812cc SVHO Yamaha Marine Engine.

How Much Horsepower Does a Yamaha FX Limited SVHO Have?

Though Yamaha no longer quotes the official WaveRunner horsepower ratings, according to the engine label, the Yamaha FX Limited SVHO is rated at 184 kW, which translates to 250 HP.

Is the Yamaha FX Limited SVHO Supercharged?

Yes, the engine of the Yamaha FX Limited SVHO is equipped with a supercharger and an external intercooler.

How Fast Can a Yamaha FX Limited SVHO Go?

Top speed of the Yamaha FX Limited SVHO is about 65-68 mph in stock condition, but this can vary depending on external conditions and the load. Overriding the speed limiter and installing some aftermarket mods result in the following top speeds:

  • 65-68 mph: In stock condition
  • 75-78 mph: Without the speed limiter
  • 80-85 mph: With some additional aftermarket modifications

How Long Does it Take a Yamaha FX Limited SVHO To Go From 0 to 60?

According to this real-world test, the Yamaha FX Limited SVHO can go from 0 to 60 mph in under 5 seconds.

How Many Passengers Can the Yamaha FX Limited SVHO Carry?

The Yamaha FX Limited SVHO can legally carry three adult riders.

How Much Weight Can a Yamaha FX Limited SVHO Hold?

The total weight capacity of the Yamaha FX Limited SVHO is 529 pounds.

What Size Storage Compartment Does the Yamaha FX Limited SVHO Have?

The Yamaha FX Limited SVHO features a glove box, large bow storage, and a smaller under-seat storage compartment with a total storage capacity of 44 gallons.

How Much Fuel Does a Yamaha FX Limited SVHO Hold?

With long tours in mind, the Yamaha FX Limited SVHO comes with an 18.5-gallon fuel tank.

How Much Oil Does a Yamaha FX Limited SVHO Take?

The total oil capacity of the Yamaha FX Limited SVHO is 5.6 quarts, but for an oil change you will need about 3.7 quarts of oil.

What is the Range on a Yamaha FX Limited SVHO?

Based on our research, the Yamaha FX Limited SVHO gets 7.5-8.0 GPH at the best cruise speed (25-26 mph). This translates to a 7-8 MPG and a fuel range of 125-130 miles, leaving the 10% reverse in the tank.

How Long is the Factory Warranty on a Yamaha FX Limited SVHO?

The factory warranty covers the Yamaha FX Limited SVHO for one year.

How Much Does a Yamaha FX Limited SVHO Cost?

In 2022, the Yamaha FX Limited SVHO is available for an MSRP of $19,099.

Where Can You Find a Yamaha FX Limited SVHO For Sale?

If you are in the market for a Yamaha FX Limited SVHO, it’s recommended that you visit the manufacturer’s official site.

You may also find our jet ski comparison tool useful, which will allow you to compare the latest models head-to-head!
